Pet Bopet Diffusion Polyester Film
ONE PLASTIC™
RY-801
100% virgin Bopet
Carton Box/ Kraft Paper/ PE Bag/ Wooden Pallet
1000 - 4000 M
| Origin: | |
|---|---|
| Application: | |
We are launching a new category of our Bopet Film products - Bopet Diffusion Polyester Film, to help you solve some problems that may exist in the fields of LCD backlight modules, photovoltaic modules, and automotive thermal insulation films.
Primer precoating applied on both sides of thefilm,which is mainly used as the substrate forLCDbacklight module brightening film processing to improve brightness and uniformity by scattering and diffusing light.
BOPET diffusion film can be used in scenes such as street lamps and indoor lighting to evenly scatter light.
The incident light will be randomly reflected and diffused on the surface of Bopet Diffusion Polyester Film, thereby improving the brightness uniformity and reducing glare.
The surface microstructure of Bopet Diffusion Polyester Film reduces the refractive index of light and improves the barrier properties of the film.
Through diffuse reflection, Bopet Diffusion Polyester Film can greatly reduce specular reflection and prevent glare on the product surface.
The product is produced in high clean and dust-freeroom with good appearance and excellent optical proper-ties. After primer precoating on both sides of the substrateit has good and stable adhesion to the brightening flm prismlayer or back coating.
Are you ready to choose a new Bopet Film for your optical products? Choose our Bopet Diffusion Polyester Film to experience a different light diffusion, while also having environmentally friendly properties, and take your product production to the next level.
| ITEM | TEST METHOD | UNIT | STANDERD VALUE | |
| Thickness | DIN 53370 | μm | 36 | |
| Average thickness deviation | ASTM D 374 | % | ± 2.0 | |
| Tensile Strength | MD | ASTM D 882 | MPa | 190 |
| TD | 210 | |||
| Break Elongation | MD | ASTM D 882 | % | 170 |
| TD | 150 | |||
| Heat Shrinkage | MD | 150°C, 30min | % | 1.6 |
| TD | 0.3 | |||
| Haze | ASTM D 1003 | % | 3 | |
| Gloss | ASTM D 2457 | % | 128 | |
| Wetting Tension | Treated Side | ASTM D 2478 | mN/m | 52 |
| Untreated Side | 42 | |||
One Plastic greets you, we are an advanced Bopet film manufacturer in China, dedicated to providing customers with a variety of customized services. In order to adapt to the different uses of Bopet Film in various places, we have launched different categories of Bopet Film, hoping to give customers a better experience.
We have been committed to the wholesale of Plastic Film, and we have lowered the price of plastic film through factory direct sales, just like the Bopet Film here. By using advanced machines and technology, as well as a strict review process, our product quality is always at a high level, and we are proud of it. As a trustworthy manufacturer, we are happy to solve various problems for our customers. Choose One Plastic, we will provide you with personalized services based on your needs and bring practical solutions to your problems.
