0.020" x 24" x 48" PETG Sheet

0.020" x 24" x 48" PETG sheet is a thin-gauge clear PETG stock supplied in a standard 24-by-48-inch sheet size. The "0.020 inch" measurement - roughly 0.5mm, also commonly written as 20 mil - makes this one of the thinner flat-stock PETG options typically ordered for thermoforming, protective covers, printing substrates, and light-duty fabrication.

This page is about the 0.020" x 24" x 48" stock specifically. If you need a broader overview of all PETG thicknesses and sizes, see our main PETG sheet page. If you need heavier-gauge PETG for rigid fabrication or machine guards, see our 3mm clear PETG sheet page. This page focuses specifically on 20 mil PETG in the standard North American 24 x 48 sheet format.

What 0.020" x 24" x 48" PETG Sheet Means

This specification breaks down as follows:

0.020 inch thickness (also written as .020", 20 mil, or approximately 0.5mm) - a thin-gauge sheet. This thickness is stiffer than film but much thinner than fabrication-grade PETG. It holds its shape flat as a sheet, but it is thin enough to thermoform easily on standard vacuum-forming equipment and flexible enough to cut with simple shop tools.

24 inch width by 48 inch length (roughly 610 x 1220 mm) - a common North American stock-sheet size. This is often referred to as a 2-by-4-foot sheet, and it is widely used because it fits on most flatbed printing tables, cuts neatly into smaller pieces, and stacks cleanly for shipping and storage.

The combination of thin 20 mil gauge and a 24 x 48 sheet size is a standard commercial stock configuration, typically chosen by buyers who need modest quantities of PETG for signage, prototyping, short-run thermoforming, or light fabrication - and who do not want to handle full 4 x 8 foot sheets.

Why Buyers Choose This Gauge and Sheet Size

Easy to Handle Alone: At 24 x 48 inches and 0.020" thick, a single sheet weighs around 0.5 kg - one person can handle, cut, and store sheets without special equipment. Larger 4 x 8 sheets often require two-person handling.

Fits Standard Small-Format Printers and CNC Tables: Most entry-level and mid-size UV flatbed printers, laser cutters, and CNC routers accommodate 24 x 48 or smaller. This stock size drops straight onto the bed without pre-cutting.

Good for Short-Run and Prototype Work: Buyers producing small quantities of printed panels, display mockups, or prototype thermoformed parts rarely need large sheets. 24 x 48 is sized for short-run projects where full industrial sheets would mean waste.

Thin Gauge Forms and Cuts Easily: 0.020" PETG vacuum-forms on light-duty and hobbyist forming equipment, not just industrial lines. It scores and snaps, cuts with utility knives, and can be processed on some light-duty laser systems, though ventilation and testing are recommended - making it a practical material for small shops and in-house prototyping.

Predictable Stock Item: Because 0.020" x 24" x 48" is a widely recognized stock format, it is easier to reorder, stock, and plan around than a custom thickness or cut size.

Common Uses for 20 Mil PETG Sheet

Thermoforming and Vacuum Forming

Shallow-to-medium depth formed parts: blister-pack shells, protective covers, packaging trays, and custom mold prototypes. 20 mil is at the upper end of what thin-gauge forming equipment (hobbyist and light-duty) handles, and at the lower end of what industrial forming lines use.

Protective Covers and Shields

Equipment protective covers, instrument panel overlays, desk guards, and light-duty barrier panels. PETG's impact resistance at 20 mil is well above that of thin PVC or APET, making it the preferred thin-gauge choice when the cover might take accidental hits.

Print Substrates and Graphics

UV flatbed printing on thin rigid sheet for displays, signage, and promotional panels. At 0.020", the sheet is thin enough to lie flat on most printer beds but rigid enough not to wrinkle during printing. For heavier-duty printing applications, see our inkjet printable PVC sheet page.

Craft, Prototype, and Model Work

Hobby thermoforming, custom cosplay props, R/C model parts, scale model components, and prototype transparent shells. 20 mil PETG cuts cleanly with shop tools, forms on simple vacuum tables, and is significantly tougher than the same thickness in acrylic.

Face Shields and Light-Duty Visors

Transparent face shields and visors where impact resistance matters but anti-fog treatment is not required. For anti-fog versions used in high-humidity environments, see our anti-fog PET sheet page.

Glazing and Partition Inserts

Light transparent glazing, partition window inserts, display cabinet fronts, and clear covers where weight and handling matter more than maximum rigidity.

PETG vs PVC, APET, and Acrylic at 20 Mil

Buyers evaluating 0.020" thin-gauge transparent sheet usually have four options: PETG, PVC, APET, and acrylic (PMMA). Here is how they compare at this thickness:

Quick guidance:

• If impact resistance and forming performance both matter, choose PETG (this page)

• If cost is the priority and the application is retail blister packaging, choose PVC blister sheet

• If the application is food-contact packaging, choose APET sheet

• If clarity and scratch resistance matter more than impact, choose acrylic (different product family)

For a broader comparison of the PET family (APET, PETG, GAG) at thermoforming thicknesses, see our APET/PETG/GAG sheet roll for thermoforming page.

Specifications

Custom sizes beyond 24 x 48 are available. If you need 4 x 8 foot sheets, metric sheet sizes, or custom cut-to-size supply, contact us with your specification.

Stock Size, Packaging, and Custom Options

For machining, die-cutting, or finishing services on PETG stock, see our machining and fabrication service.

Why Choose ONE PLASTIC?

Standard Stock Sizes and Custom Cut: We supply the 24 x 48 inch standard format for buyers who want predictable stock, and cut-to-size service for buyers with non-standard panel dimensions.

Full PETG Thickness Range: From 0.015" film stock up to 6mm fabrication plate, we manufacture PETG across the full thickness range. If your projects use multiple thicknesses, they can all come from one factory with consistent material specification.

Dedicated PET Extrusion Lines: Our PETG sheet is produced on dedicated PET-family extrusion lines with routine monitoring of thickness, clarity, and surface quality.

ISO 9001 Certified: Routine batch testing is performed for thickness tolerance, clarity, and mechanical properties. Test reports are available on request.

Custom Quote for Mixed Thickness Orders: If you need 0.020" x 24" x 48" together with other PETG thicknesses in one shipment, we can consolidate and quote the combined order.

Frequently Asked Questions

What does "020" mean in the PETG sheet spec?

"020" in this context refers to 0.020 inch (zero point zero two zero inch), sometimes written as .020" or 20 mil. It is approximately 0.5mm in metric. Plastic-sheet buyers in North America often use the three-digit form (020, 030, 040) as shorthand for thickness in thousandths of an inch.

Is 0.020" the same as 20 mil?

Yes. In US plastics terminology, 1 mil = 0.001 inch, so 20 mil = 0.020 inch. The two terms are used interchangeably in the industry.

Can I vacuum-form this thickness?

Yes. 0.020" PETG thermoforms well on both industrial vacuum-forming lines and light-duty/hobbyist forming equipment. It has a wide forming window and resists stress-whitening at bends. Pre-drying is recommended for best results - typically 65 C for 2-4 hours.

Can I cut this sheet with a laser?

Yes - with caution. PETG laser-cuts cleanly at this thickness, but fumes should be properly ventilated. Check your laser's power settings and speed for thin PETG before production runs. Mechanical cutting (CNC router, utility knife, or shear) is also straightforward at 0.020".

Can I get a 4 x 8 foot sheet instead of 24 x 48?

Yes. 24 x 48 inch is our standard stock size for this page, but we can supply 4 x 8 foot (1220 x 2440 mm) or custom sizes on request. Larger sheets typically ship better on a per-square-foot cost basis.

Is 0.020" PETG food-safe?

Food-grade PETG is available and widely used for food-contact packaging. Standard stock PETG is not specifically certified for food contact unless specified. If your application is food packaging, confirm food-grade specification at the point of order.

What is the minimum order quantity?

MOQ depends on the exact specification and quantity, including sheet count, cut size, and any custom requirements. Contact us for a specific quote based on your needs.

Get a Quote

Looking for 0.020" x 24" x 48" PETG sheet?

• Specify Your Quantity - How many sheets, and whether you need 24 x 48 only or mixed sizes

• Request Samples - Evaluate clarity, surface, and forming performance before bulk order

• Ask About Other Thicknesses - If you need multiple PETG gauges, we can quote a combined order
