ONE PLASTIC supplies 5mm clear PETG sheet as a solid, flat product for projects that require a defined metric thickness, sheet dimensions, surface, and fabrication route. Standard sheets and custom dimensions are available. Buyers comparing other thicknesses or general material choices can review our PETG sheet options. Clear is the primary color, with custom colors available. Buyers can select a gloss or matte surface, single-sided or double-sided protective film, and confirmed fabrication services before the order is reviewed.
Confirm the 5mm Sheet Specification
| Order field | Confirmed option |
| Material and form | PETG solid flat sheet |
| Nominal thickness | 5 mm |
| Standard sheet size | 1220 × 2440 mm |
| Custom dimensions | Available; final dimensions are reviewed for each order |
| Thickness tolerance | ±0.1 mm |
| Length and width tolerance | ±3 mm |
| Primary color | Clear |
| Other colors | Custom colors available |
| Surface | Gloss or matte |
| Protective film | Single-sided or double-sided |
The dimensional fields should be reviewed together. A nominal thickness alone does not define the finished part, while length, width, tolerance, surface, and film configuration can affect whether the supplied sheet matches the drawing and handling plan.
Keep 5mm Separate from 3/16 Inch
A 3/16-inch sheet converts to 4.7625 mm, so it is not automatically the same nominal specification as a 5mm sheet. ONE PLASTIC supplies this product at a nominal 5 mm with the confirmed thickness tolerance shown above. For an inch-based drawing, keep the drawing's intended nominal thickness explicit instead of replacing it with the nearest metric description.
Match Fabrication to the Drawing
Confirmed services for this product are cutting, CNC milling, and heat bending. A 5mm PETG sheet cut to size should be reviewed against the finished length, width, quantity, and required tolerances. CNC or heat-bent parts also need a dimensioned drawing that identifies the finished geometry, bend position, bend angle, and other order-specific requirements.
These services do not mean that every geometry or tolerance is accepted automatically. Feasibility is reviewed for each drawing. Processes not listed on this page require separate confirmation and are not included by assumption.
Protect the Surface and Plan Export Packing
Single-sided or double-sided protective film can be specified for the 5mm sheet. The required side configuration should be included in the order information so it can be aligned with the selected gloss or matte surface.
Confirmed flat-sheet packing uses PE film as the inner packing and kraft paper as the outer packing. Sheets are secured on a plywood export pallet with corner protection. The approximate loading reference is about one tonne per pallet. No unconfirmed board-interleaf method is included in this specification.
Confirm Commercial Terms and Technical Documents
- MOQ: 1,000 kg. No separate lower MOQ has been confirmed for custom-cut orders.
- Estimated delivery time: 7–15 days. The final delivery date is confirmed for the specific order and is not a guaranteed fixed-day commitment.
- Technical documentation: A product-level TDS for the 5mm PETG sheet can be provided. Buyer-defined document and acceptance requirements should be identified during order review.
These points allow a buyer to determine whether the order scale, planning window, and documentation path are suitable before detailed technical review.
Information Needed for Order Review
Order information should include:
- full-sheet or custom finished dimensions;
- a dimensioned drawing for CNC or heat-bent parts;
- order quantity in kilograms;
- clear or custom color;
- gloss or matte surface;
- single-sided or double-sided protective film;
- cutting, CNC milling, or heat-bending requirements;
- intended use and any buyer-defined acceptance criteria;
- packing requirements and destination.
Complete inputs allow dimensions, fabrication scope, documentation, packing, and the final delivery date to be reviewed against the same order specification.
Decision FAQ
What if a drawing requires tighter tolerances than the published values?
Include the required tolerances in the drawing for technical review. The published values should not be treated as automatic approval of a tighter requirement.
Can fabrication processes not listed on this page be assumed to be available?
No. The confirmed scope is cutting, CNC milling, and heat bending. Any additional process needs separate confirmation for the specific order.
How should engineering-document requirements be handled?
A product-level TDS can be provided. Identify the required document scope and buyer-defined acceptance criteria in the order information so they can be reviewed without adding unverified data to the product specification.
