200mm x 2mm PVC Strip Curtain Roll – 50m

The 200mm x 2mm PVC strip roll is supplied in a 50-meter roll format for fabricating and replacing PVC strip curtain systems. Supplied as a full 50-meter roll rather than pre-cut finished curtains, it allows distributors, fabricators, and industrial buyers to cut the material to the exact length required based on specific door heights and opening dimensions.

The 200mm x 2mm specification strikes a balance between flexibility, durability, and ease of installation. The PVC strip roll can be cut to size for various projects, whether for creating new PVC strip curtains or replacing existing ones. The clear PVC strip roll, also known as a transparent PVC strip roll,  maintains visibility while creating a flexible separation barrier, making it suitable to be used in warehouses, cold rooms, freezers, and industrial doorways. For bulk purchasers, the 50m roll size design reduces inventory pressure associated with stocking various fixed-length specifications and enables on-site or workshop cutting to match the actual door heights.

The 2mm thickness provides a good balance between flexibility and durability, making the roll suitable for daily access areas. And the supply with a full 50-meter roll makes it suitable for bulk purchasing and fabrication. With the flexible PVC, buyers can easily hang, move and cut, thereby meeting the customization needs of diverse clients and industrial projects. The transparent design also maintains visibility on both sides of the curtain, which makes these strip curtains suitable for warehouses, cold storage areas, industrial doorways, and similar applications.

Product Specifications

Why Choose 200mm × 2mm?

200mm × 2mm PVC strip curtains offer a practical balance of flexibility, ease of passage, and isolation effectiveness, making them particularly suitable for doorways with frequent foot traffic and for small-to-medium-sized openings. Compared to other thicker and wider options such as 300mm x 3mm or 400mm x 4mm strips, the 200mm x 2mm variant is lighter and more pliable, allowing for easier opening and smoother retraction, making them ideal for applications involving personnel doors, small-to-medium openings, warehouses, and cold rooms. For procurement projects requiring a balance between daily traffic efficiency and basic isolation capabilities, the 200mm x 2mm specification is generally the more economical choice, as well as being easier to process and install.

200mm x 2mm vs Other Sizes

How Many PVC Strips Can Be Cut From a 50m Roll?

A 50m roll can be cut into different strip lengths according to doorway height. Without considering cutting waste, one roll can produce approximately:

The actual number of door openings that can be covered depends on the opening width, the overlap ratio between strips, and the installation method. For bulk projects, purchasers can estimate material usage per roll based on required door dimensions, thereby facilitating procurement, inventory management, and cost budgeting.

Recommended PVC Strip Curtain Overlap Ratio

When selecting PVC strip curtains, the doorway width and the overlap between strips directly affect their thermal insulation, dustproofing, windproofing, and zone isolation effects. Buyers can choose from overlap rates of 25%, 50%, or 75% based on the doorway environment, foot traffic, and wind pressure requirements.

Generally, a 25% overlap is suitable for small or indoor doorways with high foot traffic and low wind pressure. A 50% overlap is a commonly used balancing solution that strikes an optimal balance between ease of passage and isolation effectiveness, and it is suitable for warehouses, cold storage facilities, and general industrial doorways. A 75% overlap is appropriate for applications requiring high levels of cold insulation, wind protection, and dust exclusion, or where significant temperature differences, strong airflows, and high wind pressures exist. While a higher overlap ratio ensures greater coverage between strips, it also increases resistance when passing through and raises the amount of PVC material required.

For example, when using 200mm PVC strips, the actual effective coverage width varies according to the overlap ratio. Wider doorways and higher overlap ratios require a greater number of PVC strips. Therefore, distributors and project buyers should consider doorway width, strip width, overlap, traffic frequency, and on-site wind pressure before determining the final number of strips and the installation method.

For 200mm x 2mm PVC strip curtain rolls, purchasers can select the appropriate overlap ratio for their specific project, and cut the 50m roll to the required door height, allowing for flexible accommodation of installation and replacement strip requirements for doorways of various sizes.

PVC Strip Curtain Quantity Calculator (200mm Wide PVC Strip)

Calculation Formula

Number of PVC Strips Required = Door Width ÷ Effective Coverage Width per Strip

Example:

For a 2-meter wide doorway using 200mm PVC strips with 50% overlap:

Strip width: 200mm

Effective coverage width: 100mm

Door width: 2000mm

Calculation:

2000mm ÷ 100mm = 20 strips

Therefore, approximately 20 pieces of PVC strips are required.

Clear Smooth vs Ribbed PVC Strip

The primary difference between clear smooth PVC strips and ribbed PVC strips lies in their surface structure and intended operating environments. Clear smooth PVC strips feature a flat surface and high transparency with excellent visibility, so they are used for doorways with frequent pedestrian traffic, food processing areas, general warehouses, and standard industrial doors. They are generally the preferred choice for applications requiring a balance of visibility, pedestrian access, and routine partitioning.

In contrast, ribbed PVC strips utilize a ribbed surface structure to better withstand daily contact and friction, making them better suited for high-traffic areas frequented by hand trucks, pallet jacks, and forklifts. In applications where strips are prone to rubbing against each other or coming into direct contact with vehicles and cargo, ribbed PVC strips reduce direct surface friction and provide better surface protection for high-frequency usage environments.

Therefore, buyers can make their selection based on specific application needs. Clear smooth strips are suitable for standard doorways where visibility and pedestrian access are priorities, while ribbed strips are a better choice for environments involving hand trucks, pallet handling, and high-frequency traffic.

Where Is 200mm x 2mm PVC Strip Curtain Used?

The 200mm x 2mm PVC strip curtain is suitable for a wide range of commercial and industrial doorways requiring flexible partitioning, reduced air exchange, and dust control. It provides excellent flexibility and ease of access for areas with high foot traffic where visibility must be maintained while minimizing airflow.

Warehouse Doorways

The PVC strips produced from this roll are suitable for warehouse entrances and internal passageways, helping reduce air exchange and the ingress of dust and external contaminants while allowing quick passage for personnel and light equipment.

Cold Rooms / Chillers

For cold rooms, cold storage, and chiller zones, the strip curtains can serve as a flexible thermal barrier. For low-temperature environments, the appropriate standard grade or polar PVC strip curtains should be selected based on operating temperatures to ensure the material maintains good flexibility during use.

Food Processing Areas

The strip curtains can be used for flexible partitioning between food processing, packaging, and other production zones, and it helps delineate work areas while maintaining easy access for personnel. For actual use, PVC materials meeting the relevant standards should be selected based on specific hygiene requirements.

Workshops

The PVC curtains are suitable for entrances to factories, workshops, and production areas, and act as a flexible barrier between personnel walkways and production zones, reducing dust, drafts, and cross-contamination between areas.

Retail Back Rooms

Suited for separating back-of-house areas, stockrooms, and workspaces in retail stores, the PVC plastic strips provide simple, effective spatial separation for storage areas without affecting the daily passage of personnel.

PVC Replacement Strips for Existing Curtain Systems

The roll format is suitable for producing PVC replacement strips for existing strip curtain systems. Distributors, curtain fabricators, or end-users can cut the 200mm x 2mm PVC strips to the required length based on existing doorway heights, allowing for the replacement of aged, damaged, or worn strips without needing to replace the entire strip curtain system.

FAQ

Is 200mm x 2mm suitable for forklift traffic?

200mm x 2mm PVC strips are generally more suitable for pedestrian traffic and light-to-medium traffic. For frequent forklift or pallet traffic, 300mm x 3mm or 400mm x 4mm may provide better durability and resistance to displacement.

Can I use 200mm x 2mm PVC strips in a freezer?

Yes, but you need to select the appropriate grade of PVC strips based on the actual operating temperature. For low-temperature or cold-storage environments, it is recommended to use polar PVC strip curtains or low-temperature PVC strips specifically designed for such conditions rather than standard PVC.

How many strips can I cut from one 50m roll?

It depends on the required strip length. For example, a 2.0m length yields approximately 25 strips, a 2.5m length, about 20 strips, and a 3.0m length, about 16 strips. The actual quantity should also account for cutting loss.

What overlap should I use for 200mm PVC strips?

Common overlap ratios include 25%, 50%, and 75%. A 25% overlap is suitable for areas with high foot traffic, 50% is appropriate for general warehouses and industrial doorways, and 75% is better suited for applications requiring superior cold insulation or wind protection. The specific choice should be based on the doorway environment and traffic requirements.

Can you supply pre-cut strips instead of 50m rolls?

Pre-cut PVC strips can be provided based on project requirements. Please specify the required length, quantity, and width when placing your order so that a specific supply plan can be confirmed.

What is the weight of one 200mm x 2mm x 50m roll?

The roll weight depends on PVC density, formulation, and packaging method. Net weight and gross weight can be provided according to the actual production specification. Roll diameter and pallet loading information can also be provided for bulk orders.

Are mounting rails and hangers available?

We can provide matching PVC strip curtain rails, hangers, hooks, and other installation accessories based on project requirements. If you only need the PVC strips, we can also supply them in full 50-meter rolls.

What is the difference between standard and low-temperature PVC?

The primary differences lie in flexibility and performance in low-temperature environments. Standard PVC is suitable for general temperature conditions such as normal warehouse, workshop and industrial environments, whereas low-temperature or polar PVC is specifically designed for colder environments, including cold rooms, chillers and freezer applications, where the material can maintain superior flexibility at low temperatures. The specific grade should be selected based on the actual operating temperature.

What is the MOQ for 200mm × 2mm PVC Strip Curtain Roll 50m?

MOQ depends on the product type, PVC grade, packaging requirements, and order quantity. Standard PVC strip rolls usually require a lower MOQ than special formulations such as anti-static or welding PVC strips. Actual MOQ may vary depending on specifications and packaging.

Typical MOQ Reference for Bulk PVC Strip Curtain Orders

How is the 50m PVC Strip Curtain Roll packaged?

50m PVC strip rolls are securely wrapped in PE film and packed on standard export pallets for safe transportation. Loose loading in containers with protective cardboard is also available. Custom packaging is available upon request.
