Hook-Forming and Branch-Binding All-in-One Machine
ONE PLASTIC's hook-forming and branch-binding all-in-one machine is designed for artificial Christmas tree branch production. It combines branch binding, wire-end hook forming, label sleeving and adjustable segment settings in one workflow, helping factories reduce separate handling steps while keeping production parameters easier to control.
The machine is suitable for Christmas tree branch binding, label-sleeving and hook-forming production where wire size, segment quantity and leaf arrangement need to be matched to the required tree specification.
Quick Buyer Notes
| Machine type | Integrated branch binding and hook forming machine |
| Application | Artificial Christmas tree branch production |
| Main process | Wire sorting, branch binding, segment setting, hook bending and label sleeving |
| Quotation details | Send wire diameter, wire length, branch design, output target, voltage requirement and delivery destination. |
![Hook forming and branch binding all-in-one machine for artificial Christmas tree production]()
Technical Specifications and Parameters
| Parameter | Specification |
| Device name | Hook-Forming And Branch-Binding All-in-One Machine |
| Overall dimension | 2660 x 650 x 1410 mm |
| Package size | 2510 x 670 x 1470 mm |
| Rated voltage | 220 V |
| Rated power | 3400 W |
| Applicable wire | 2-6 mm straight wire |
| Wire length range | 100-650 mm |
| Number of binding segments | 1-20 segments |
| Leaf arrangement | 1-8 pine leaves each, according to branch design |
| Designed output | 20,000-40,000 leaves/day |
| Thread finish | Ultrasonic wave |
| Packing | Wooden box |
Integrated 2-in-1 Production Process
The integrated design is intended to reduce repeated transfer between separate branch-binding and hook-forming equipment. The touch screen supports multi-language human-machine interface dialogue for parameter setting and equipment running-status monitoring, helping operators match the machine to different artificial tree branch specifications.
Automatic sorting for 2-6 mm straight wire.
Segmental binding from 1 to 20 segments.
Online hook bending for 7-shape and 9-shape branch-end designs.
Online layer label sleeving for production identification.
Touch-screen operation: Supports a multilingual interface for parameter setting and equipment running-status monitoring.
One-key start and stop, fault detection, alarm and stop protection.
End knotting process designed to avoid smoke, smell and heating during operation.
 Machine structure and operation area. | ![Branch binding and hook bending machine production detail]() Production detail for artificial Christmas tree branches. |
Applications in Christmas Tree Manufacturing
This machine is suitable for factories producing artificial Christmas tree branches in different lengths, segment counts and leaf arrangements. Before ordering, provide the target branch structure and wire specification so ONE PLASTIC can review whether the machine configuration matches the required production plan.
| Artificial Christmas trees | Branch binding lines | Hook-end branch production |
Production Video
Use the production video together with your sample branch drawing to confirm wire feeding, binding segment arrangement and hook forming requirements.
Packaging, Shipping and Project Support
The machine is packed in a wooden box for shipment. For project orders, please confirm the destination, voltage requirement, spare-part requirements and any installation or debugging support needed before quotation.
![Wooden box packing for branch binding and hook forming machine]()
Quotation Checklist
To help ONE PLASTIC review the correct machine configuration, send the following details with your inquiry:
Wire diameter and wire length range.
Required branch length, segment count and leaf arrangement.
Expected daily output and working shift plan.
Voltage, plug and workshop power requirements.
Sample branch photos, drawings or reference products.
Destination port or delivery address for shipping quotation.
Frequently Asked Questions
What is the main advantage of this integrated machine?
It combines branch binding and wire-end hook forming in one workflow, reducing the need to move semi-finished branches between separate machines.
What wire range can the machine handle?
The applicable straight wire diameter is 2-6 mm, with a wire length range of 100-650 mm. The final suitability should be checked against your branch sample.
Can the machine make different branch designs?
Yes. The page specification states 1-20 binding segments and 1-8 pine leaves each. Please provide drawings or physical samples so the configuration can be reviewed.
How should I request a quotation?
Send the wire specification, branch design, target output, voltage requirement, order quantity and shipping destination. A video or photo of the target branch is helpful for technical confirmation.
Request a Quote
Contact ONE PLASTIC with your branch sample, wire specification and production target. The team can review the required machine configuration, packing details and delivery arrangement according to your project.
